I-690v Wall-down-inyuka isihluzi esisebenzayo
Fumana i-690v yodonga-i-filter esebenzayo ye-filter yenziwa eTshayina, inika umgangatho ophezulu wokusebenza kunye nokuthembeka. UGeya ubonelela ngezisombululo eziphezulu zokusebenza nenkonzo ekhethekileyo. Ukufumana eyona nto ilungileyo ye-prielist, shiya umyalezo wakho ngezantsi, kwaye siza kubuyela kuwe ngokukhawuleza!
I-690v yodonga-i-Wall-inyuka i-filter ye-filter (AHF) ibonelela ngokuthintela ukusebenza okuphezulu kweenkqubo ezintathu zeSigaba seSigaba seSigaba seSigaba seSigaba seSigaba se-690V. Ukuqesha i-DSP + i-CPL yedijithali yoLawulo lweDijithali kunye ne-Topology yeNqanaba amathathu, le AHF iqinisekisa imbuyekezo echanekileyo. Isolo semodyuli sayo ixhasa ukufakelwa okufihlakeleyo ngonxibelelwano olufanayo, ukwenza ugcino kunye nendawo efanelekileyo. I-690v yodonga-i-Ahft i-AHF ifihla i-ahft i-falltonics evela kwi-2nd ukuya kwi-50th off, ifikelele kwinqanaba le-95% lokucoca izinga lokucima. Nge-100Arated yangoku kunye nobungakanani be-492mm X 675mm X 275mm (i-DWH), le yunithi efakwe eludongeni ibonelela ngezisombululo ezisemgangathweni zoMbane eziphezulu.
Inkcazo yemodeli:
| Gy | Ahf | 0.4 | 50a | / | 4l | W |
| Ikhowudi yeShishini | Isihluzi esisebenzayo | Inqanaba le-voltage 0.69: 690v ± 20% |
I-100 ye-Kvar) 100a | I-3l: isigaba esithathu esithathu I-4l: iSigaba se-5 se-4 |
W: udonga |
Iimbonakalo:
● Sebenzisa i-DSP + CPDA YONKE INDLELA YOKUZIPHATHA NGOKUGQIBELA
● Ukuthatha uyilo lwemodyuli, eququzelela unxibelelwano olufanayo lwemodyuli ezininzi, kuthatha indawo encinci kwaye kulula ukuyigcina.
● Uyilo lolwakhiwo lwezinto ezizimeleyo zomoya kunye neendawo zokugcina izithembiso ziqinisekisa ukusebenza kwezinto.
● Ingayicoca i-cofatics kuluhlu olubanzi lwee-fats, ukusuka kwi-2 ukuya kwi-50 i-vismonics, kunye nokusombulula ingxaki yokungalingani kwesithathu ngaxeshanye.
● Izinga lokucoca i-filting liphezulu. Ukuba umthamo uvumela, inqanaba elihambelana nokubila ngoku lingaphezulu lama-95%. Seta i-100% yemveliso yangoku yokubeka umda ukuqinisekisa ukusebenza kwexesha elide lwezixhobo.
Izicelo:
I-690v Wall-Udonga I-Fillters esebenzayo i-filters ibalulekile ekuqinisekiseni umgangatho wombane othembekileyo kwizicelo eziphezulu zevolthi:
● Iindawo ezinomzi mveliso:Ukukhusela izixhobo ezinobuthathaka kunye nokugcina umsebenzi uzinzo kumashishini njengokumbiwa, ioyile kunye negesi, kunye nemveliso eninzi apho kuxhaphakile khona iinkqubo ezingama-690v.
● I-High-Postries motor motor:Ukunciphisa ukugqwetha okulinganayo okubangelwe ziimoto ezinkulu zemoto, ukuphucula ukusebenza kwenkqubo kunye nokunciphisa ukusetyenziswa kwamandla.
● Iinkqubo ezihlaziyiweyo zamandla:Ukutshintsha kwamandla okwenza izinto kunye nokuthomalalisa i-distoortic i-protortic ezingeniswe yimithombo yamandla ahlaziyiweyo kwiimeko zokudibana okuphezulu.
● Izibonelelo eziNgcali:Ukubonelela ngamandla acocekileyo kunye nezinzileyo kwizibonelelo ezibalulekileyo ezisebenza kwiinkqubo ezingama-690v, ukuqinisekisa ukusebenza okuqhubekayo.
I-690v Wall-Udonga I-Fillters ebonakalayo esebenzayo yokuzisa unciphiso olusebenzayo noluthembekileyo lokunxibelelana kwezicelo eziphezulu ze-voltage.
Iparamitha zobugcisa:
| I-220V uthotho | 380v Serichunge | I-500v Series | I-690v Series | ||
| Ukuphakama | <2000m, ngaphezulu kwe-2000m, i-DEFRAY NO-GB / T3859.2 | ||||
| Ubushushu obugciniwe | -20 ~ + 50 ℃ | ||||
| Ubuntu bezizalwane | ≤90%, akukho uqinisekiso kumphezulu xa ubushushu benyanga ubuncinci bungama-25 ℃ | ||||
| Inqanaba lokungcola | Inqanaba le-III ngezantsi | ||||
| I-Voltage eSebenzayo | I-AC220V ± 20% | I-AC380V ± 20% | I-AC500V ± 20% | I-AC690V ± 20% | |
| Ukusebenza rhoqo | I-50hz ± 5% | ||||
| Imbuyekezo yangoku | 25A | 25/50/75/100 / 150A | I-100a | I-100a | |
| Isakhiwo seGridi | L / n | I-3P3W / 3P4W | I-3P3W / 3P4W | I-3P3W / 3P4W | |
| Inani leeyunithi idityaniswe kwi-parallel | Incitshisiwe | ||||
| Ukusebenza kakuhle komatshini ngokubanzi | ≥97% | ||||
| Isakhiwo seGridi | 32kz | 16kz | 12.8KHz | 12.8KHz | |
| Uluhlu lweMbuyekezo | 2 ~ 50 Amaxesha, inqanaba leMbuyekezo eliThengiswayo lihlengahlengiswa | ||||
| Ukuchongwa komsebenzi | Amandla asebenzayo | Amandla asebenzekileyo, amandla asebenzayo + Asymmetry | |||
| Amandla asebenzayo Imbuyekezo iMbuyekezo | ≥95% | > I-92% | |||
| Ukuhluma okungathathi hlangothi amandla | Ukubanakho kwe-nehlalting yomgca kukucoca amaxesha ama-3 okwesigaba sokucoca kwinqanaba | ||||
| Ixesha lokuphendula elipheleleyo | <10ms | <40ms | <40ms | <40ms | |
| Ingxolo | ≤60DB | ≤60DB | ≤65db | ≤65db | |
| Indlela yokulawula | I-2--Indlela ye-R485 ye-Nokia (ixhasa i-GPRS / WiFi) | ||||
| Ukhuseleko | Ukulayisha ngaphezulu, isoftware / isoftware ephezulu, i-overvolstage ye-grid kunye nokungaphantsi komhlaba, ukusilela kwamandla, ukhuseleko olungaqhelekanga, i-qho. | Ukulayisha ngaphezulu, isoftware / isoftware i-hardcurrent, i-grid overvolstage, i-Grid Vilage, ukusilela kwamandla, ukusilela kwamandla, ukhuseleko lwe-proquency, njl. | |||
| Indlela yokufaka | I-rack / i-wall-ikhutshiwe | Rack | |||
| Umgca ongenayo | Umqolo ongenayo (Uhlobo lwerack), ingenangaphezulu (i-Wall-inyuka) | Umgca ongenayo | |||
| Inqanaba lokhuseleko | IP20 | ||||
Imodeli kunye nokucaciswa:
| Iimodeli | ||||
|---|---|---|---|---|
| Inombolo yemodeli | Ikalwe okwangoku (a) | I-Voltage yeNkqubo (v) | Ubungakanani (d * h * h) | Indlela yokupholisa |
| I-GY APF-0.22-25a / 2l-r / w | 25 | 220 | I-220 * 330 * 160mm | Ukunyanzelwa kokupholisa umoya |
| I-GY APF-0.4-25a / 4l-r / w | 25 | I-380 ± 20% | I-460 * 490 * 89mm | |
| I-GY APF-0.4-50A / 4l-r / w | 50 | I-380 ± 20% | I-460 * 490 * 89mm | |
| I-GY APF-0.4-75A / 4l-r / w | 75 | I-380 ± 20% | I-500 * 510 * I-190mm | |
| I-GY APF-0.4-100a / 4l-r / w | 100 | I-380 ± 20% | I-500 * 550 * 240mm | |
| I-GY APF-0.4-150A / 4l-r / w | 150 | I-380 ± 20% | I-500 * 550 * 240mm | |
| I-GY APF-0.5-100a / 4l-r / w | 100 | I-500 ± 20% | I-495 * 675 * 275mm | |
| I-GY APF-0.69-100a / 4l-r / w | 100 | I-690 ± 20% | I-495 * 675 * 275mm | |
Iithegi ezishushu: I-690v Wall-down-inyuka isihluzi esisebenzayo
