I-380v Wall-Wall-inyuka i-filter esebenzayo
UGeya ubonelela nge-380v enyuka udonga lokuhluza i-filter, eyilwe kwaye yenziwe kuMzi-mveliso wethu wase-China ngetekhnoloji ye-Advarvery. Ukusebenza kakuhle, kulula ukuyifaka, kwaye ithembekile kwizicelo ezahlukeneyo. Nxibelelana nathi malunga neenkcukacha ezithe kratya kwaye ufumane ezona zinto zibalaseleyo!
I-380v yahlulwa i-filter ye-filter ye-witsion ye-380v (AHF) ibonelela ngesisombululo se-gold sotsonation sokuncitshiswa kwesigaba sesithathu (3p4w) kunye nenqanaba le-380v). Ukuqesha i-DSP ePhambili ye-DSP + i-CPLM yedijithali kunye ne-topology yenqanaba le-3, le ndawo yokugcina indawo ihambisa imbuyekezo ebonakalayo. Iimpawu eziphambili zibandakanya uluhlu olubanzi lokucoca ubuchwephesha (2 ukuya kwi-50th), iqondo eliphezulu lokucoca (ukuya kuthi ga kwi-95%), kunye noyilo oluhamba ngemozulu yoqhagamshelo oluhle nolondolozo. Ifumaneka kwimilinganiselo eyahlukeneyo yangoku (i-25a ukuya kwi-150A), i-380v inyuka i-AHF iqinisekisa umgangatho oqingqiweyo nolwazi ngokufanelekileyo kwimveliso yezomsebenzi.
Inkcazo yemodeli:
| Gy | Ahf | 0.4 | 50a | / | 4l | W |
| Ikhowudi yeShishini | Isihluzi esisebenzayo | Inqanaba le-voltage I-0.4: 380v ± 20% |
Umthamo omiselweyo (Kvar) 25/50/75 / 100 / 150a | I-3l: isigaba esithathu esithathu I-4l: iSigaba se-5 se-4 |
W: udonga |
Iimbonakalo:
● Sebenzisa i-DSP + CPDA YONKE INDLELA YOKUZIPHATHA NGOKUGQIBELA
● Ukuthatha uyilo lwemodyuli, eququzelela unxibelelwano olufanayo lwemodyuli ezininzi, kuthatha indawo encinci kwaye kulula ukuyigcina.
● Uyilo lolwakhiwo lwezinto ezizimeleyo zomoya kunye neendawo zokugcina izithembiso ziqinisekisa ukusebenza kwezinto.
● Ingayicoca i-cofatics kuluhlu olubanzi lwee-fats, ukusuka kwi-2 ukuya kwi-50 i-vismonics, kunye nokusombulula ingxaki yokungalingani kwesithathu ngaxeshanye.
● Izinga lokucoca i-filting liphezulu. Ukuba umthamo uvumela, inqanaba elihambelana nokubila ngoku lingaphezulu lama-95%. Seta i-100% yemveliso yangoku yokubeka umda ukuqinisekisa ukusebenza kwexesha elide lwezixhobo.
Izicelo:
I-380v Wall-Wall-inyuka i-Fillters esebenzayo ye-active ibalulekile ekugcineni umgangatho wamandla kuluhlu lwezicelo zemizi-mveliso:
● I-Automast Autous:Ukukhusela izixhobo ze-Automangi ezibuthathaka kunye nokuqinisekisa ukusebenza ngokuthethwa kukuqhutywa rhoqo kwi-RESTEARDS (VFDS), iirobhothi, kunye neminye imithwalo ebaluleke kakhulu.
● Izityalo zeMveliso:Ukuphuculwa komgangatho wamandla kunye nokunciphisa iindleko zamandla ngokunciphisa ukungavisisani.
● Amaziko eDatha:Ukubonelela ngamandla acocekileyo ukuze kugxilwe kwizibonelelo ze-IT kwaye kuthintele ilahleko yedatha ngenxa yokuguquguquka kwamandla.
● Ishishini leoyile negesi:Ukuqinisekisa ukusebenza okuthembekileyo kweempompo, iingcingo zezixhobo ezibalulekileyo kwiindawo ezinobunzima.
● Iinkqubo ezihlaziyiweyo zamandla:Ukudibanisa imithombo yamandla ahlaziyiweyo kwigrid ngelixa ugcina umgangatho wamandla kunye nozinzo.
Iifilitha ezingama-380v zalukene nodonga oluzenzekelayo zibonelela ngesisombululo esithembekileyo nesisebenza ngokufanelekileyo somgangatho wamandla ofanelekileyo kwizicelo ezintathu zeSigaba 380V.
Iparamitha zobugcisa:
| I-220V uthotho | 380v Serichunge | I-500v Series | I-690v Series | ||
| Ukuphakama | <2000m, ngaphezulu kwe-2000m, i-DEFRAY NO-GB / T3859.2 | ||||
| Ubushushu obugciniwe | -20 ~ + 50 ℃ | ||||
| Ubuntu bezizalwane | ≤90%, akukho uqinisekiso kumphezulu xa ubushushu benyanga ubuncinci bungama-25 ℃ | ||||
| Inqanaba lokungcola | Inqanaba le-III ngezantsi | ||||
| I-Voltage eSebenzayo | I-AC220V ± 20% | I-AC380V ± 20% | I-AC500V ± 20% | I-AC690V ± 20% | |
| Ukusebenza rhoqo | I-50hz ± 5% | ||||
| Imbuyekezo yangoku | 25A | 25/50/75/100 / 150A | I-100a | I-100a | |
| Isakhiwo seGridi | L / n | I-3P3W / 3P4W | I-3P3W / 3P4W | I-3P3W / 3P4W | |
| Inani leeyunithi ezixhunyiwe kwi-parallel | Incitshisiwe | ||||
| Ukusebenza kakuhle komatshini ngokubanzi | ≥97% | ||||
| Isakhiwo seGridi | 32kz | 16kz | 12.8KHz | 12.8KHz | |
| Uluhlu lweMbuyekezo | 2 ~ 50 Amaxesha, inqanaba leMbuyekezo eliThengiswayo lihlengahlengiswa | ||||
| Ukuchongwa komsebenzi | Amandla asebenzayo | Amandla asebenzekileyo, amandla asebenzayo + Asymmetry | |||
| Inqanaba leMbuyekezo yamandla aSebenzayo | ≥95% | > I-92% | |||
| Amandla okuhluma ngokungathathi hlangothi | Ukubanakho kwe-nehlalting yomgca kukucoca amaxesha ama-3 okwesigaba sokucoca kwinqanaba | ||||
| Ixesha lokuphendula elipheleleyo | <10ms | <40ms | <40ms | <40ms | |
| Ingxolo | ≤60DB | ≤60DB | ≤65db | ≤65db | |
| Indlela yokulawula | I-2--Indlela ye-R485 ye-Nokia (ixhasa i-GPRS / WiFi) | ||||
| Ukhuseleko | Ukulayisha ngaphezulu, isoftware / isoftware ephezulu, i-overvolstage ye-grid kunye nokungaphantsi komhlaba, ukusilela kwamandla, ukhuseleko olungaqhelekanga, i-qho. | Ukulayisha ngaphezulu, isoftware / isoftware i-hardcurrent, i-grid overvolstage, i-Grid Vilage, ukusilela kwamandla, ukusilela kwamandla, ukhuseleko lwe-proquency, njl. | |||
| Indlela yokufaka | I-rack / i-wall-ikhutshiwe | Rack | |||
| Umgca ongenayo | Umqolo ongenayo (Uhlobo lwerack), ingenangaphezulu (i-Wall-inyuka) | Umgca ongenayo | |||
| Inqanaba lokhuseleko | IP20 | ||||
Imodeli kunye nokucaciswa:
| Iimodeli | ||||
|---|---|---|---|---|
| Inombolo yemodeli | Ikalwe okwangoku (a) | I-Voltage yeNkqubo (v) | Ubungakanani (d * h * h) | Indlela yokupholisa |
| I-GY APF-0.22-25a / 2l-r / w | 25 | 220 | I-220 * 330 * 160mm | Ukunyanzelwa kokupholisa umoya |
| I-GY APF-0.4-25a / 4l-r / w | 25 | I-380 ± 20% | I-460 * 490 * 89mm | |
| I-GY APF-0.4-50A / 4l-r / w | 50 | I-380 ± 20% | I-460 * 490 * 89mm | |
| I-GY APF-0.4-75A / 4l-r / w | 75 | I-380 ± 20% | I-500 * 510 * I-190mm | |
| I-GY APF-0.4-100a / 4l-r / w | 100 | I-380 ± 20% | I-500 * 550 * 240mm | |
| I-GY APF-0.4-150A / 4l-r / w | 150 | I-380 ± 20% | I-500 * 550 * 240mm | |
| I-GY APF-0.5-100a / 4l-r / w | 100 | I-500 ± 20% | I-495 * 675 * 275mm | |
| I-GY APF-0.69-100a / 4l-r / w | 100 | I-690 ± 20% | I-495 * 675 * 275mm | |
Iithegi ezishushu: I-380v Wall-Wall-inyuka i-filter esebenzayo
